Specifications:
| Model | CS-C6c-R100-8G8WF |
| Camera | |
| Image sensor | 1/2.7" Progressive Scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| Lens | 4mm@ F1.6, view angle:106° (Horizontal), 90° (Vertical), 48°(Diagonal) |
| PT Angle | Pan: 340° , Tilt: 130° |
| Minimum Illumination | 0.51Lux @(F1.6, AGC ON) with IR |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto switch |
| DNR | 3D DNR |
| WDR | Ture WDR |
| BLC | Supports |
| Night Vision | 10m &Smart Color Night Vision 6m |
| Video & Audio | |
| Max. Resolution | 3840× 2160 |
| Frame Rate | Self-Adaptive during network transmission |
| Video Compression | H.265/H.264 |
| Video Bit Rate | HD; Standard. Adaptive bit rate. |
| Audio Bit Rate | Self-Adaptive |
| Max. Bitrate | 4Mbps |
| Network | |
| Wi-Fi Standard | IEEE802.11a, IEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz、 5.17GHz~5.25GHz， 5.735GHz~5.835GHz |
| Channel Bandwidth | Support 20MHz |
| Security | WPA-PSK/WPA2-PSK/ WPA3-Personal |
| Transmission Rate | 11b: 11Mbps, 11g :54Mbps, 11n :72Mbps |
| Wi-Fi Pairing | AP pairing |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| Wired Network | No |
| Function | |
| Smart Alarm | AI Human Detection |
| Customized Alert Area | Supports |
| Two-way Talk | Supports ( Two Mic ) |
| General Function | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
| Storage | |
| Local Storage | Micro SD card slot (Max. 512G) |
| Cloud Storage | EZVIZ Cloud Storage |
| General | |
| Operating Conditions | -10ºC ~ 45ºC ( 14°F to 113 °F ), Humidity 95% or less ( non-condensing) |
| Power Supply | DC 5V/2A（ Type-C) |
| Power Consumption | MAX. 8W |
| Dimensions | 100mm x 100mm x 96.5mm |
| Packaging Dimensions | 115.5mmx116mmx160 mm |
| Weight | Product: 290gWith Package: 604 |
